Digital Signage
Related Links:
Bypass LAN Switch for Internet Security

In-line monitoring for intrusion prevention / detection
Provides fail-safe access through bypass LAN ports

MultiLAN
CLICK HERE FOR SMALL FORM FACTOR MULTI-LAN SOLUTIONS
NIS-101

NIS-101

NIS-101

NIS-101

Specifications:
Intel Core i3 / i5 / i7 / Xeon E1200 Series Processor
Up to 16GB DDR3 2 Channel Memory
6 x Intel Gigabit RJ45 Port (Intel 82574L)
2 x by-pass LAN
1 x PCIe 8x expansion slot
1 x PCIe 8x LAN Module port
3 x SATA, 1 x CF and 1 x IDE Connectors
4 x USB 2.0 (2 front ports, 2 from Header)
2 x RS-232 Serial Port (1 x RJ45 and 1 Header)
1 x 4-in / 4-out GPIO Header
1 x VGA port on back panel
1U Chassis 12.99" depth short rackmount
250W 100V-240V AC Power Supply

  • Operating Temperature: 0 to +55 °C
  • Non operating temperature: -20 to +70 °C
  • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
  • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
  • Shock - Operating 3,920 m/s2 (400G) 2ms
  • Shock - Non-Operating 8,820 m/s2 (900G) 1ms
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)
  • FCC, CE, UL, RoHS
NIS-102

NIS-102

NIS-102

NIS-102

Specifications:
Intel Atom D525 Processor
Up to 4GB DDR3 Memory
6 x Intel Gigabit RJ45 Port (Intel 82574L)
2 x by-pass LAN
1 x PCI 32-bit expansion slot
2 x SATA, 1 x CF Connectors
4 x USB 2.0 (2 front ports, 2 from Header)
2 x RS-232 Serial Port (1 x RJ45 and 1 Header)
1 x 4-in / 4-out GPIO Header
1 x VGA port on back panel
1U Chassis 12.99" depth short rackmount
150W 100V-240V AC Power Supply

  • Operating Temperature: 0 to +55 °C
  • Non operating temperature: -20 to +70 °C
  • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
  • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
  • Shock - Operating 3,920 m/s2 (400G) 2ms
  • Shock - Non-Operating 8,820 m/s2 (900G) 1ms
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)
  • FCC, CE, UL, RoHS
NIS-104

NIS-103

NIS-103

NIS-103

Specifications:
Intel Celeron 1037u Processor
Up to 8GB DDR3 Memory
6 x Intel® Gigabit RJ45+4SFP Ports
Intel I211-AT/i350-AM4 , 3 x By-pass
1 x PCIe x8 Slot for LAN Module
1 x PCIe x8 standard slot
3 x SATA, 1 x CF Connectors
4 x USB 2.0 (2 front ports, 2 from Header)
2 x RS-232 Serial Port (1 x RJ45 and 1 Header)
1 x 4-in / 4-out GPIO Header
1 x VGA port on back panel
1U Chassis 14.76" depth short rackmount
150W 100V-240V AC Power Supply

  • Operating Temperature: 0 to +55 °C
  • Non operating temperature: -20 to +70 °C
  • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
  • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
  • Shock - Operating 3,920 m/s2 (400G) 2ms
  • Shock - Non-Operating 8,820 m/s2 (900G) 1ms
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)
  • FCC, CE, UL, RoHS
NIS-201

NIS-201

NIS-201

Specifications:
Intel E3 series Xeon or Core i3 / i5 / i7 Processor C206 Chipset
Up to 32GB DDR3 2 Channel Memory with ECC option
Base Network Module: 2 x Intel Gigabit RJ45 Port (Intel 82574L) 2 x by-pass ports
Optional Network Module: (up to three modules selection)
8 x Intel Gigabit RJ45 Port (Intel I350AM4/82580EB), 2 x by pass ports
8 x Intel Gigabit SFP Port (Intel I350AM4/82580EB)
4 x Intel Gigabit SFP Port (Intel 82580EB)
4 x Intel Gigabit RJ45 Port (Intel 82580EB), 2 x by pass ports
4 x Intel 10Gigabit SFP Port (Intel 82599ES)
2 x Intel 10Gigabit SFP Port (Intel 82599ES)
1 x PCIe 8x expansion slot
3 x Network Module expansion port (PCIe 8x)
3 x SATA, 1 x CF and 1 x IDE Connectors
4 x USB 2.0 (2 front ports, 2 from Header)
2 x RS-232 Serial Port (1 x RJ45 and 1 Header)
1 x 4-in / 4-out GPIO Header
1 x VGA port on back panel
2U Chassis 21.6" depth rackmount
SKU# 201-01:
3 Network Modular Slot, 2 x Hot swap hard Drive bay, 1 LCD Control Module
SKU# 201-02:
3 Network Modular Slot, 3 x Hot swap hard Drive bay
300W 100V-240V AC Power Supply

  • Operating Temperature: 0 to +55 °C
  • Non operating temperature: -20 to +70 °C
  • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
  • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
  • Shock - Operating 3,920 m/s2 (400G) 2ms
  • Shock - Non-Operating 8,820 m/s2 (900G) 1ms
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)
  • FCC, CE, UL, RoHS
NIS-202

NIS-202

NIS-202

Specifications:
Intel E3 series Xeon or Core i3 / i5 / i7 Processor
Up to 32GB DDR3 2 Channel Memory with ECC option
Base Network Module: 6 x Intel Gigabit RJ45 Port (Intel 82574L) 2 x by-pass ports
Optional Network Module: (one slot to choose any one of the following option)
8 x Intel Gigabit RJ45 Port (Intel I350AM4/82580EB), 2 x by pass ports
8 x Intel Gigabit SFP Port (Intel I350AM4/82580EB)
4 x Intel Gigabit SFP Port (Intel 82580EB)
4 x Intel Gigabit RJ45 Port (Intel 82580EB), 2 x by pass ports
4 x Intel 10Gigabit SFP Port (Intel 82599ES)
2 x Intel 10Gigabit SFP Port (Intel 82599ES)
1 x PCIe 8x expansion slot
1 x PCIe 8x expansion port
3 x SATA, 1 x CF and 1 x IDE Connectors
4 x USB 2.0 (2 front ports, 2 from Header)
2 x RS-232 Serial Port (1 x RJ45 and 1 Header)
1 x 4-in / 4-out GPIO Header
1 x VGA port on back panel
2U Chassis 21.6" depth rackmount
300W 100V-240V AC Power Supply

  • Operating Temperature: 0 to +55 °C
  • Non operating temperature: -20 to +70 °C
  • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
  • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
  • Shock - Operating 3,920 m/s2 (400G) 2ms
  • Shock - Non-Operating 8,820 m/s2 (900G) 1ms
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)
  • FCC, CE, UL, RoHS
NIS-203

NIS-203

NIS-203

NIS-203

Specifications:
Intel® C2758 8-Core Processor
Up to 64GB DDR3 2 Channel Memory with ECC option
Base Network Module: 4 x Intel Gigabit RJ45 Port (Intel i347) 2 x by-pass ports
Optional Network Module: (up to four modules selection)
8 x Intel Gigabit RJ45 Port (Intel I350AM4/82580EB), 2 x by pass ports
8 x Intel Gigabit SFP Port (Intel I350AM4/82580EB)
4 x Intel Gigabit SFP Port (Intel 82580EB)
4 x Intel Gigabit RJ45 Port (Intel 82580EB), 2 x by pass ports
4 x Intel 10Gigabit SFP+ Port (Intel 82599ES)
2 x Intel 10Gigabit SFP+ Port (Intel 82599ES)
1 x PCIe 8x expansion slot
4 x Network Module expansion port (PCIe 8x)
4 x SATA, 1 x CF and 1 x IDE Connectors
4 x USB 2.0 (2 front ports, 2 from Header)
2 x RS-232 Serial Port (1 x RJ45 and 1 Header)
1 x 4-in / 4-out GPIO Header
1 x VGA port on back panel
2U Chassis 21.6" depth rackmount
SKU# 201-01:
3 Network Modular Slot, 2 x Hot swap hard Drive bay, 1 LCD Control Module
SKU# 203-02:
4 Network Modular Slot, 1 x Hot swap hard Drive bay
300W 100V-240V AC  Redundant Power Supply

  • Operating Temperature: 0 to +55 °C
  • Non operating temperature: -20 to +70 °C
  • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
  • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
  • Shock - Operating 3,920 m/s2 (400G) 2ms
  • Shock - Non-Operating 8,820 m/s2 (900G) 1ms
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)
  • FCC, CE, UL, RoHS
LAN Modules

  ISM-801R     ISM-801S

  • 8 x Intel Gigabit RJ45 Ports (Intel I350AM4/82580EB)
  • 2 x Bypass PCIe 8x busISM-801R

  • 8 x Intel Gigabit SFP Ports (Intel I350AM4/82580EB)
  • PCIe 8x bus
    ISM-801R

  ISM-401R     ISM-401S



  • 4 x Intel Gigabit RJ45 Ports (Intel 82576EB)
  • PCIe 8x bus, 2 Bypass
    ISM-801R

  • 4 x Intel Gigabit SFP Ports (Intel 82576EB)
  • PCIe 8x bus
    ISM-801R

  ISM-401W     ISM-201W



  • 4 x Intel 10 Gigabit SFP+ Ports (Intel 82599ES)
  • PCIe 8x bus
    ISM-801R

  • 2 x Intel 10 Gigabit SFP+ Ports (Intel 82599ES)
  • PCIe 8x bus
    ISM-801R

  ISMD-201S

  • 2 x Intel Gigabit SFP Ports (Intel I210-IS)
  • PCIe 8x bus
    ISM-801R
