Processor
• Dual Intel 6th Gen Xeon® Birch Stream-Sp , up to 144 cores each , max 350W, Support 6700P, 6500P, 6700E series CPU.
Memory
• 32 × DDR5 slots (RDIMM)，16-channel (8-channel per CPU), up to 5600MHz, support RDIMM/3DS RDIMM • Up to 8TB ECC
|
Graphics
• Up to 8 Dual-Slot NVIDIA RTX PRO™ 6000/5000/4500/4000, A100, H100, H100NVL, H200NVL, A800, H800 GPU cards via PCIe 5.0 16x slots
Storage
• Supports 8 / 12 × 3.5” or 24 × 2.5” HDDs • Supports 4 × U.2 NVMe SSD, 2 × M.2 PCIe4.0 4x/SATA SSD，2280/22110
|
Expansion Slot
• Up to 11 × standard expansion slots • Up to 8 × FHFL GPU cards • Supports 1 × PCIe5.0 16x + 2 × PCIe4.0 8x (in addition to 8 GPU)
Network
• Supports 1 x OCP3.0 expansion slot standard with PCIe 5.0 8x, (16x is optional) • LAN Options: 4 x 1GbE / 2 x 10Gb SFP+ / 4 x 10Gb SFP+/ 2 x 25Gb SFP28 • Supports NCSI
|
I/O
• 1 × VGA • 1 × COM • 2 × USB3.0 • 1 × IPMI RJ45 • 1 × Standard OCP NIC 3.0 slot
Front Panel
• 2 x USB3.0 • 1 x VGA optional
|
Internal I/O
• 2 × USB 3.0 header, 2×USB 2.0 header, 1× USB 2.0 Type A • 1 × VROC Key header • 12 × SATA 3.0 (3 × SFF-8643), supports RAID 0,1,5,10 • 3 × MCIO （PCIe 5.0 8x), supports 6 × NVMe（PCIe 5.0 4x） • 2 × M.2, PCIe 4.0 4x , 2280 & 22110 • 12 × 4 pin FAN • 1 × VGA header for FP • 1 × SPI TPM 2.0
Chassis
4U 19" Standard Rackmount
• 2.5” Configuration: W 448mm × H 175mm × D 772mm （792mm with ear bezel） • 3.5” Configuration: W 448mm × H 175mm × D 822mm （842mm with ear bezel）
|
Power Supply
• 4 x Standard CRPS Power Modules, hot-swappable, supports 2+2/ 3+1/ 1+1 redundancy • 1600W/2000W/2400W/2700W Platinum or Titanium power supply module optional
OS Support
• Windows Server, Linux
|
Applications
• GPU Cluster for AI, Deep Learning, HPC.
Environment
• Non-operating Temperature: -40 to +70 C • Operating Relative Humidity: 10% to 80% (non-condensing • Non-operating Relative Humidity: 10% to 93% (non-condensing) • MTBF: 100,000 Hours • FCC, CE, UL, RoHS Compliance
|
