Processor
• Supports AMD EPYC™ 9005*/9004 (with AMD 3D V-Cache™ Technology) and 97x4 series processors
Memory
• 8 DIMM slots (1DPC) • Supports DDR5 288-pin RDIMM, RDIMM-3DS • RDIMM: 96GB (2R),RDIMM-3DS: 512GB (2S8Rx4)
|
Graphics
• ASPEED AST2600 • DDR4 512MB
OS and Storage Manager
• Microsoft ® Windows:- Server 2019 (64bit)- Server 2022 (64 bit), Linux OS and NAS/iSCSI WEB based Manager • Optional: Solaris, MS Storage Server, VMware, FreeBSD, Other Open Soruce Linux.
|
File System
• XFS, EXT3 standard • Optional: ZFS, NTFS, or any file system supported by the x86 platform
Network I/O
• Intel® X550-AT2: 2 RJ45 (10GbE). Optional 2 or 4 additional 10/25/100/100GbE by Card • 1 dedicated IPMI
|
Network Service
• DHCP client/server (default is DHCP client/static) • Network Protocol: CIFS/SMB, NFS, FTP • iSCSI / NAS / SAN (Can be mixed)
Management Interface
• Web GUI • E-mail notification • Local Host Access via VGA and Keyboard
|
Expansion Slot
• 4 FHHL PCIe5.0 x16 slots
Remote Boot Function
• Requires NIC with PXE support on client
|
File Sharing
• Authorizes users to access shared folder using passwords (by default, there is one "Public" shared folder)
Access Control
• Allows users to access shared files for "Read Only" or "Read/Write"
|
Storage/RAID
• 60 Hot-swap 3.5" SATA/SAS Top Loaded drive bays, 8 Optional Hot-swap 2.5" U.2 NVMe Rear drive bays • 2 M-key (PCIe5.0 x4); support 2280/2260/2242/2230 form factor • 8 Hot-swap 2.5'' NVMe (PCIe5.0 x4) drive bays* *Supports TA@30C *Additional RAID/HBA card required to support the 60 x 3.5" SATA/SAS drives • 8-ports NVMe passive backplane • 2 x 30-port 12G SAS backplanes with 40-PHY expander
I/O
• 2x Type-A(USB 3.2 Gen1) rear connectors • VGA graphics • 2 x SATA-6G/s, 4 SATA-3G/s SATA port, optional SAS ports supported • Optional: 2 additional I/O (such as COM, PS/2, TPM) supported by header or add-on
|
Client Support
• MS Windows®11,10,8, 7, XP and Windows Server, Linux , FreeBSD, Solaris and Mac • Snap Shot Backup and Recovery Client Support • Active Directory, Rsync are supported
Remote Controls
• Power on/off, system reset + USB
• IPMI, KVM over IP, Remote Power On/Off is supported
|
Indicators
• Power, LAN and HDD LEDs
|
Cooling
• Rear: 9 x 40 x 56mm hot-swap fans for HDD Bays + 4 x 60 x 38mm fans for MB
Power Supply
• 2+2 CRPS power supply (4 x 800W 80-Plus Platinum modules) 100-240V 60/50Hz UR/FCC/CE Certified
|
Operating Temperature
• From 0 °C to 40 °C (32°F to 104 °F)
Non-Operating Temperature
• From 0 °C to 40 °C (32°F to 104 °F)
|
Operating Humidity
• From 10% to 90% relative humidity
|
Dimensions
• 4U Rackmount Chassis • Dimensions: 17.1" W x 7" H x 33.5" D • Weight: 200 lb.
Warranty
• SAS and SATA-E Hard Driver carry 5 year,SATA-N carries 3 year
• Base system:3 year standard parts and depot labor;lifetime toll free phone support.
• Optional:3 or 5-year(total years) extended warranty with advanced parts replacement service.
• Optional:7+year extended warranty service available.
• On-site service is available with additional cost.
|
